Relay G5V-2, 5V DC/125V AC 2A

The OMRON G5V-2 is a miniature PCB signal relay with a 5 V DC coil and two changeover contacts (DPDT, 2 Form C). It is suitable for switching low to medium loads in control and signal circuits where defined electrical strength and repeatable switching parameters are required.

Technical specifications

• Model series: G5V-2 (standard version)
• Coil voltage: 5 V DC
• Contact arrangement: DPDT (2c, 2 Form C)
• Contact type: bifurcated cross contact
• Contact material: Ag + Au alloy
• Rated load (resistive): 0.5 A at 125 VAC; 2 A at 30 VDC
• Rated continuous contact current: 2 A
• Maximum switching voltage: 125 VAC, 125 VDC
• Maximum switching current: 2 A
• Contact resistance: max. 50 mΩ
• Switching time: max. 7 ms
• Opening time: max. 3 ms
• Insulation resistance: min. 1000 MΩ (at 500 VDC)
• Dielectric strength: between coil and contacts 1000 VAC (50/60 Hz, 1 min); between contacts 750 VAC (50/60 Hz, 1 min); between contacts of different polarity 1000 VAC (50/60 Hz, 1 min)
• Impulse withstand voltage: 1500 V (10 x 160 µs)
• Mechanical life: min. 15,000,000 switching cycles
• Electrical life: min. 100,000 switching operations (at 1800 switching operations/h)
• Ambient operating temperature: -25°C to 65°C (no icing or condensation)
• Operating ambient humidity: 5% to 85%
• Weight: approximately 5 g

Functions and features

• Two changeover contacts for simultaneous switching of two independent branches
• Suitable for signal and control applications requiring stable insulation parameters
• Fast response (typically in the order of milliseconds) for common switching tasks
• Au-doped contacts for more reliable switching of low signal levels within specifications

Ideal for

• Control and signal circuits in industrial electronics
• Switching signal paths, logic levels and low-voltage loads
• Automation, measuring technology and laboratory products
• Switching DC loads up to 30 VDC within rated values

Package contents

• OMRON G5V-2 relay, 5 V DC coil

Why choose this product?

• Proven DPDT (2 Form C) design for universal use in signal and control circuits
• Clearly defined switching and insulation parameters for the design of reliable devices
• Standard version suitable for common applications with 5 V DC coil

Installation and operating instructions

• When designing a printed circuit board, observe the recommended insulation distances and track widths according to the switching voltage and current.
• To achieve the declared service life, use the relay within the rated values for the given load type (resistive/inductive)
• For inductive loads, consider using appropriate suppression (e.g. RC element, diode, varistor) depending on the type of power supply and load.

Safety notice

• The relay is capable of switching voltages up to 125 VAC / 125 VDC; when working with hazardous voltages, ensure adequate shielding, protection and compliance with safety standards
• Only perform installation and service when the power supply is disconnected.
