Rectangular rocker switch KCD1-203, black 250V/6A

The rocker switch KCD1-203 is a panel switch designed for switching two independent circuits. The design with 6 terminals and marking of positions I and II corresponds to the ON1-ON2 function, not to simple ON-OFF switching. It is suitable for mounting in a panel or device housing where mechanical switching between two operating states is required.

Technical specifications

• Type: KCD1-203
• Design: rocker switch
• Number of pins: 6
• Function: ON1-ON2
• Rated voltage and current: 250 V AC / 6 A
• Mounting hole: 20 x 13 mm
• Dimensions: 21 x 15 x 19 mm
• Color: black

Functions and features

• 6-pin design for two independent circuits.
• Rocker control with marking of positions I and II.
• Rectangular body for mounting in a panel cutout.
• The terminals are intended for electrical connection to the device circuit.
• The design is suitable for use as a panel switch in electrical and electronic equipment.

Ideal for

• Panel control of electrical devices.
• Switching of two circuits in devices and switchboards.
• Repairs and replacements of compatible rocker switches of the same type and size.
• Installation in plastic or metal housings with a corresponding mounting hole.

Package contents

• 1x rocker switch KCD1-203

Why choose this product?

• Clearly designated 6-pin design for ON1-ON2 function.
• Compact panel dimensions for standard rectangular cutout.
• A suitable solution for applications where a simple ON-OFF switch is not required, but switching between two states.
• The basic electrical and dimensional parameters listed allow compatibility checks when replacing the original element.

Installation and operating instructions

• Before installation, verify the dimensions of the panel cutout and the arrangement of the connection pins in the specific wiring.
• Only install the switch in a device whose electrical parameters match the switch's rated values.
• When connecting, it is necessary to correctly identify individual contacts according to the diagram of the specific application.
• Assembly and connection must be carried out in such a way as to prevent the terminals from loosening or short-circuiting between the contacts.

Safety notice

• The product is designed to work with electrical voltages, including 250 V AC. Incorrect connection may result in electric shock or damage to the device.
• Only carry out assembly and connection when the power supply is disconnected.
• The connection should be carried out by a person with appropriate electrical qualifications.
• Do not exceed the rated electrical load of 250 V AC / 6 A.
• Do not use the switch if it is mechanically damaged or if the connection terminals are damaged.
