Start-up capacitor CD60, 450V, 100uF

The CD60 capacitor is designed for starting circuits of single-phase electric motors, where it provides the necessary phase shift and increase in starting torque. It is particularly suitable for applications powered from a 230VAC network, typically pumps, compressors and other devices with an auxiliary winding.

Technical specifications

• Type designation: CD60
• Capacitance: 100 µF
• Tolerance: ±5%
• Rated voltage: 450 VAC
• Rated frequency: 50/60 Hz
• Dimensions: 80x35mm
• Design: cylindrical housing, conductor terminals

Functions and features

• Designed for short-term engine starting mode (starting capacitor)
• Support for starting single-phase asynchronous motors using phase shifting
• Compact cylindrical design suitable for installation in equipment
• Wire terminals for direct connection to the circuit

Ideal for

• Starting circuits of single-phase electric motors
• Pumps, fans, compressors and similar equipment with auxiliary windings
• Service replacement of starting capacitors in domestic and industrial applications

Package contents

• 1 pc of capacitor CD60 450VAC / 100µF with wires

Why choose this product?

• Clearly defined electrical parameters for motor starting applications
• Rated voltage 450VAC for use in mains applications with adequate headroom
• Simple connection using wire terminals

Installation and operating instructions

• Before installation, verify that the capacitance and rated voltage match the original capacitor and the motor requirements.
• Use the starting capacitor only in a circuit with a switching element (e.g. centrifugal switch, relay) that disconnects it after starting.
• Always safely discharge the capacitor using the appropriate procedure before handling.

Safety notice

• The product is intended for use with hazardous AC voltage (mains applications). Only perform installation when the power supply is disconnected.
• Improper connection or use outside the intended mode may result in damage to the device and risk of electric shock.
• After disconnecting the power supply, the capacitor may remain charged; discharge is necessary before touching the terminals.
