Automatic light switching unit for LEDs

Universal automatic light switching unit.

6.67 €

6.67 € Tax excluded

6.67 € without VAT i
The applied VAT rate is 0% for the country United States.
check In stock
Download PDF

The SK-CD105 is an intelligent control module designed for eagle eye LED daytime running lights (DRL) or other LED DRL modules. It offers automatic DRL on/off functions when the low beam is turned on and a practical departure mode with a delay after the engine is turned off. It protects the car battery by monitoring the voltage and allows for easy installation without complex electronics.

Technical specifications

  • Model: SK-CD105
  • Operating voltage: 12 – 18 V DC
  • Working current: up to 5 A
  • Starting voltage threshold: ≥ 13 V
  • Voltage cut-off threshold: < 12.5 V
  • Exit mode duration: approx. 15 s
  • Maximum power of connected DRLs: 18 W (pair)
  • Brightness control method: PWM (when connecting the yellow wire)
  • Installation: vehicle interior, protected from moisture

Functions and features

  • Automatic DRL lighting when the engine is started if the voltage reaches ≥ 13 V.
  • Automatic DRL shutdown when voltage drops below 12.5 V, with the option to extend the lighting time if voltage remains higher.
  • Departure mode – DRLs remain on for approximately 15 seconds after the engine is turned off for safe exit from the vehicle.
  • Possibility to dim the DRL to half brightness when turning on the dipped beam or reading lights (by connecting the yellow wire).
  • The SK-CD105 model allows you to completely turn off the DRL when turning on the low beams.
  • Easy installation directly on the vehicle battery with integrated fuse.

Ideal for

  • Passenger cars
  • Deliveries
  • Motorcycles (with 12V installation)
  • LED eagle eye daytime running lights, LED strips, LED DRL modules

Package contents

  • 1× LED DRL automatic switching unit SK-CD105
  • Installation wires with fuse
  • Quick start guide (EN/CZ)

Why choose this product?

  • Fully automatic DRL control without driver intervention.
  • Car battery protection thanks to low voltage shutdown.
  • Increased security thanks to exit mode with delayed switch-off.
  • Easy installation even for the average user.
  • Possibility to choose between dimming or completely turning off the DRL when turning on the low beams.
OEM
SK-CD105
Voltage
12 V DC
Waterproof grade
IP22
