Fan 100x100x33mm, 12V DC, IP20, BA10033B12U

BA10033B12U is an axial DC fan designed for forced cooling of electronics and power components in industrial equipment. Thanks to the double ball bearing design, it is suitable for long-term operation and applications where stable mechanical life is required.

Technical specifications

• Model: BA10033B12U
• Rated power supply: DC 12V
• Current consumption: 2.40 A
• Dimensions: 97 × 97 × 33 mm
• Bearing type: double ball bearing
• Lifespan: 100,000 hours (at 25°C, 45-85% RH)
• Additional function: support for speed control function (speed function) - control method and interface not specified in the source documents

Functions and features

• Maintenance-free design with double ball bearing
• Design focused on sufficient airflow and static pressure to cool closed cabinets and densely packed assemblies
• Suitable for continuous operation in typical industrial environments

Ideal for

• Cooling of power supplies, converters, UPS and charging systems
• Switchboards, industrial control units and communication equipment
• Cooling of power modules, heat sinks and electronics cabinets with limited airflow

Package contents

• 1× DC fan BA10033B12U

Why choose this product?

• 12 V DC power supply suitable for common industrial and embedded applications
• Double ball bearing for stable operating characteristics and long-term use
• Compact size of 97 x 97 x 33 mm for integration into devices with limited space

Installation and operating instructions

• Before installation, check the available DC 12 V power supply and the power reserve of the power supply (at least according to the fan consumption).
• Ensure correct airflow direction in the device and sufficient intake/exhaust openings.
• If you are using speed control, verify the compatibility of the control signal/controller with the specific fan design (the interface is not specified in the source documents).

Safety notice

• The fan is a rotating device - during operation, provide mechanical protection against contact with the blades.
• Before working on the wiring, disconnect the power supply and prevent accidental start-up.
• Observe the correct polarity of the DC 12 V power supply; incorrect connection may damage the fan or power supply.
